3D Print Toolbox
3D Print Toolbox 1.1 is a wonderful software to get you started with 3D printing.
What does 3D Print Toolbox 1.1?
3D Print Toolbox is a set of tools that help you to prepare models for 3D printing. These tools include graphical visualization, geometry transformations, creation of control programs. The program allows you to place your models in the workspace of 3D printer and cut 3D image into the layers.
Operating systems:
Windows 7 or higher (32/64 bit).
Requires Microsoft .NET Framework 4.6.
System requirements:
- OpenGL 4.1;
- Intel Core 2 or AMD Athlon 64 or newer;
- 205 MB available hard disk space;
- 4GB RAM memory.
Get 3D Print Toolbox now!

Basic functionality of 3D Print Toolbox 1.1:
- loads 3D object from STL file;
- creates hollow model with a specified wall thickness;
- slices model into layers;
- generates control program for printing in the format of G-code.
Steps to printing a 3D model:
1. You’ll need a 3D model.The model in the format STL file is created in 3D-editors or downloaded from free sources. Our program works with a single model that is placed in the center of 3D-image area and its size should fit the printing workspace. Area size is specified in the dialog 3D Printer.
2. Operations with loaded model file.
You can zoom in/out the 3D view with mouse wheel, rotate it with pressed mouse wheel. Use pressed mouse wheel and key Shift to move 3D view. Use buttons to set front and top views.
Fill, transparency or triangles.
Start procedure for slicing into layers according to settings of 3D printer area. You can see horizontal section of model for each slice.
You can make hollow model with a specified wall thickness. To see the hollow, it is necessary to switch on the checkbox Slice or use transparency and triangles views.
The program does not produce G-code directly for a specific printer. You can use created G-code as a geometric template to add more processing instructions.
7. Visualization of the control program.
Use any G-code simulator.
8. 3D print your model.
Control program is loaded into a 3D printer and starts printing.
